Configuration Class Blocks
Each sublibrary of the Embedded Target for Motorola MPC555 library contains a configuration class block that has an icon similar to the one shown in this picture.
| Note Configuration class blocks exist only to provide information to other blocks. Do not copy these objects into a model under any circumstances. |
CAN Message Blocks and CAN Drivers Libraries
| Block Name |
Purpose |
| CAN Message Packing |
Map Simulink signals to CAN messages. |
| CAN Message Packing (CANdb) |
Pack Simulink double signals into CAN messages. |
| CAN Message Filter |
Dispatch message processing based on message ID. |
| CAN Message Unpacking |
Inspect and unpack the individual fields in a CAN message. |
| CAN Message Unpacking (CANdb) |
Decompose a CAN frame into its constituent signals. |
| Block Name |
Purpose |
| Vector CAN Configuration |
Configure a CAN channel (either hardware or virtual) for use with Vector-Informatik drivers. |
| Vector CAN Receive |
Read CAN frames from a Vector CAN channel. |
| Vector CAN Transmit |
Transmit CAN frames on a Vector CAN channel. |
