Embedded Target for Motorola MPC555

TouCAN Soft Reset

Reset a TouCAN module

Library

Embedded Target for Motorola MPC555

Description

When the TouCAN Soft Reset block executes, the TouCAN module resets its internal state. The TouCAN error counters will be reset. The Fault Confinement State will be reset to the Error Active state, provided the TouCAN module has not reached the Bus Off state.

We recommend that you place this block in a triggered subsystem, with a sample time of -1 (inherited).

Dialog Box

Module

Select TouCAN module A or B.

Sample time

Sample time of the block.
